L3 HARRIS LOCUST™ FIELD TERMINAL & SPEAKER RF-7980-ST001 FOR MILITARY RADIOS
***BATTERY NOT INCLUDED***
CONDITION:
NEW OLD STOCK IN OEM BOX
DESCRIPTION:
L3 HARRIS PN: RF-7980-ST001
PN: 12260-1000-01
CAGE: 7QAK7
SUMMARY:
The Locust Field Terminal and Speaker (RF-7980-S1001) is designed for use with the AN/PRC-117G, AN/PRC-152A, AN/PRC-160, RF-7800H-MP, RF-7850M, RF-7800M-HH, RF-7800M-MP, RF-7850S and RF-7800V.
DESCRIPTION:
The L3Harris Locust provides audio, call tone generation and detection via field wire, and radio traffic through a standard 6-pin ADF connector.
This compact, interoperable solution features an integrated speaker for clear, loud audio, allowing users to monitor radios with or without headset. Locust provides top performance in Point-To-Point and mixed networks and supports remote radio audio when two or more locusts are used.
LOCUST™ FIELD TERMINAL AND SPEAKER SPEC SHEET
Compatibility:
AN/PRC-152A, RF-7800M-HH, AN/PRC-117G, RF-7800M-MP, AN/PRC-160, RF-7800H-MP, RF-7850M, RF-7850S, RF-7800V
PHYSICAL
Dimensions:
7.4 H x 2.3 D x 3.0 W in (18.8 H x 5.8 D x 7.6 W cm)
Weight:
2.05 lbs (with 12041-2400-0x battery)
1.2 lbs (without battery)
Color/Finish:
Black
Shock and Vibration:
Designed to meet MIL-STD-810G 516.5 Procedure IV, 514.6 Procedure I and II
Temperature:
Designed to meet MIL-STD-810G 501.5 Procedure I, II and III, 502.5 Procedure I and II, 503.5 Procedure I
Sand/Dust/Salt Fog/Rain:
Designed to meet MIL-STD-810G 510.5 Procedure I and II, 509.5 Procedure I, 506.5 Procedure I
Humidity:
Designed to meet MIL-STD-810G 507.5 EMI/RFI Designed to meet MIL-STD-461G RS103, RE101, RE102 and CE101
INTERFACES
Audio Input:
U329/U standard 6-pin ADF
Audio Output:
U329/U standard 6-pin ADF
Field Wire Binding Posts:
Two binding posts capable of accepting stranded 1.25 mm diameter wire
Battery Connector:
Connector that accepts a 12041-2400 or 12500-2500 battery with a clip for retention
Function Button:
PTT
Volume up / call tone
Volume down / call tone
Menu
—
