Introducing the folder "Chernobyl 1986"
Working project. Drawings of heating and ventilation systems, water supply and sewerage.
Ministry of Automobile Transport of the Ukrainian SSR
Site for the collection and temporary storage of solid household waste and oils.
This folder contains 7 drawings:
1. Site for the collection and temporary storage of solid waste and oils.Oil change site.General information.
2. Site for the collection and temporary storage of solid waste and oils.Oil change site.Heating and ventilation plan at the 0.006 mark.Installation of the P1 system
3.Site for the collection and temporary storage of solid waste and oils.Oil change site.Heating and heat supply schemes.Water unit.
4. Solid waste and oil collection and temporary storage area. Oil change area. General information.
5. Solid waste and oil collection and temporary storage area. Oil change area. Water supply and sewerage network plan.
6. Solid waste and oil collection and temporary storage area. Oil change area. Network diagrams B1, T3, B3, K3, K1.
7. Production building diagram. Wells, settling oil trap.
